JAY PARTS PITMAN BUSHING RENEGADE OUTLANDER 2012+

JAY PARTS BUSHING PITMAN CAN AM G2, 2012-

Large tolerances in the bushings lead to high wear. That's why we laser-measured all components in order to produce the exact bushing for the CanAm Pitman G2.
The bushings were made of PE-GL as a wear-resistant and self-lubricating material and provided with an inner spiral groove to ensure sufficient all-around lubrication. An O-ring seals off dirt and water.

FEATURES
- bushing PE-GL
- inner spiral groove
- special dimension

ATTENTION:
Use the bushing exclusively with the Pitman
We made a different dimension for the steering column. Part number JP0196

ASSEMBLY
The installation by your specialist workshop is advisable.
Check your Pitman for wear! Our bushing fits the JAY PARTS Pitman as well as the original Pitman but cannot repair a worn Pitman!
Use plenty of waterproof grease when assembling. Our spiral groove ensures effective long-term lubrication

SCOPE OF DELIVERY
2x bushings halves
2x O-ring NBR

WORKS WITH THE FOLLOWING MODELS:
Can Am Outlander 500 – 1000, 2012 +
Can Am Renegade 500 – 1000, 2012 +
